Question or issue on macOS:
I am using the gfortran compiler on mac osx mavericks. I have installed Xcode and command line tools. I am trying to compile a simple helloworld program with gfortran to test whether everything works, but unfortunately it doesn’t work. The error message seems to suggest that I have no main function, but I don’t see the error in the code:
But when i try to compile using
I get the following error:
I do not understand what is wrong and I am on the verge of despair. I tried with gfortran 4.8.2 as well as gfortran 4.9.0, I tried reinstalling Xcode and Command Line Tools but nothing seems to work.
I am aware similar questions have been asked, but I was not able to find a solution to my problem. I would be happy even with a sloppy workaround, as long as I can get the compiler to run…
How to solve this problem?
Oh my dear. Found the solution about a minute after staring the bounty. Rather than using the recommended installer from https://gcc.gnu.org/wiki/GFortranBinaries I just installed it with
The gfortran now compiled without complaining.
Hope this helps!
Undefined Symbols For Architecture X86_64 Mac
Hi there!
I'm really new in all of this, and I don't know anything about terminal and stuff... I (think) installed openCV 2.4.10 and qtCreator 3.3.0 using terminal commands:
- cd /Users/Sergio/Downloads/opencv-2.4.9
- mkdir build
- cd build
- cmake -G 'Unix Makefiles' ..
- make -j8
- sudo make install
It seems ok, folders appear on usr/local/... I don't know how to use QtCreator so I create a console project and add this to the .pro:
@
#-------------------------------------------------
#-------------------------------------------------
QT += core
QT -= gui
TARGET = cosa
CONFIG += console
CONFIG -= app_bundle
TEMPLATE = app
QMAKE_MACOSX_DEPLOYMENT_TARGET = 10.9
SOURCES += main.cpp
INCLUDEPATH += '/usr/local/include'
LIBS += -L'/usr/local/lib'
-lopencv_core
-lopencv_highgui
@
Then into the main.cpp added this (from an example i got online):
@
#include 'opencv2/opencv.hpp'
#include 'opencv2/highgui/highgui.hpp'
using namespace cv;
int main( int argc, char **argv)
{
Mat image = imread( argv[1], CV_LOAD_IMAGE_COLOR );
namedWindow( 'Original', CV_WINDOW_NORMAL | CV_WINDOW_KEEPRATIO | CV_GUI_EXPANDED );
imshow( 'Original', image );
// Sobel example from http://docs.opencv.org/doc/user_guide/ug_mat.html#visualizing-images
Mat gray;
cvtColor( image, gray, CV_BGR2GRAY );
Mat sobelx;
Sobel( gray, sobelx, CV_32F, 1, 0 );
double minVal = 0.0;
double maxVal = 0.0;
minMaxLoc( sobelx, &minVal, &maxVal ); //find minimum and maximum intensities
Undefined Symbols For Architecture X86_64 Mac Clion
Mat draw;
sobelx.convertTo( draw, CV_8U, 255.0/(maxVal - minVal), -minVal * 255.0/(maxVal - minVal) );
namedWindow( 'Sobel', CV_WINDOW_NORMAL | CV_WINDOW_KEEPRATIO | CV_GUI_EXPANDED );
imshow( 'Sobel', draw );
while ( waitKey( 33 ) != 27 )
;
return 0;
}
@
When I click on Run (is that the way I should do that?) in the issue section displays:
@error: symbol(s) not found for architecture x86_64
error: linker command failed with exit code 1 (use -v to see invocation)@
And the compile output shows this:
@09:59:55: Running steps for project cosa...
09:59:55: Configuration unchanged, skipping qmake step.
09:59:55: Starting: '/usr/bin/make'
/Users/Sergio/Qt5.4.0/5.4/clang_64/bin/qmake -spec macx-clang CONFIG+=debug CONFIG+=x86_64 -o Makefile ../cosa/cosa.pro
/Applications/Xcode.app/Contents/Developer/Toolchains/XcodeDefault.xctoolchain/usr/bin/clang++ -headerpad_max_install_names -Wl,-syslibroot,/Applications/Xcode.app/Contents/Developer/Platforms/MacOSX.platform/Developer/SDKs/MacOSX10.10.sdk -mmacosx-version-min=10.9 -Wl,-rpath,/Users/Sergio/Qt5.4.0/5.4/clang_64/lib -o cosa main.o -F/Users/Sergio/Qt5.4.0/5.4/clang_64/lib -L/usr/local/lib -lopencv_core -lopencv_highgui -framework QtCore -framework DiskArbitration -framework IOKit
Undefined symbols for architecture x86_64:
'cv::namedWindow(std::string const&, int)', referenced from:
_main in main.o
'cv::Sobel(cv::_InputArray const&, cv::_OutputArray const&, int, int, int, int, double, double, int)', referenced from:
_main in main.o
'cv::imread(std::string const&, int)', referenced from:
_main in main.o
'cv::imshow(std::string const&, cv::_InputArray const&)', referenced from:
_main in main.o
'cv::cvtColor(cv::_InputArray const&, cv::_OutputArray const&, int, int)', referenced from:
_main in main.o
'std::allocator<char>::allocator()', referenced from:
_main in main.o
'std::allocator<char>::~allocator()', referenced from:
_main in main.o
'std::basic_string<char, std::char_traits<char>, std::allocator<char> >::basic_string(char const*, std::allocator<char> const&)', referenced from:
_main in main.o
'std::basic_string<char, std::char_traits<char>, std::allocator<char> >::~basic_string()', referenced from:
_main in main.o
'std::ios_base::Init::Init()', referenced from:
___cxx_global_var_init in main.o
'std::ios_base::Init::~Init()', referenced from:
___cxx_global_var_init in main.o
ld: symbol(s) not found for architecture x86_64
clang: error: linker command failed with exit code 1 (use -v to see invocation)
make: *** [cosa] Error 1
09:59:55: The process '/usr/bin/make' exited with code 2.
Error while building/deploying project cosa (kit: Desktop Qt 5.4.0 clang 64bit)
When executing step 'Make'
09:59:55: Elapsed time: 00:00.@
Why is that? can anybody help me, please? I read a lot about it but i can't understand a word :(
I need to start using this programs in a class and i don't have any idea about anything!!
Thank you :)
